INA3608

Name: INA3608
Brand: IBASE Technology
SKU: INA3608
Availability: InStock

Mainstream 1U Network Security Server with 14th/13th/12th Gen Intel® Core™ Processors (formerly Raptor Lake-S) & up to 16GbE and Dual 10G ports

Mainstream 1U Network Security Server with 14th/13th/12th Gen Intel® Core™ Processors (formerly Raptor Lake-S) & up to 16GbE and Dual 10G ports. Local warranty support and engineering customization available on request.

CPU

LGA1700 Socket for 14th/13th/12th Gen Intel® Core i Processors

MEMORY

2x DDR5 UDIMM 4800 MHz, up to 128 GB

STORAGE

1x 2.5” HDD/SSD1x SATA DOM1x 2280 M.2 slot

DISPLAY

1x LCM

Mainstream 1U Network…Rackmount Network Appliance

REQUEST QUOTE DATASHEET (PDF)

P/N # INA3608

Manual Driver

Specifications

18 ROWS

CPU	LGA1700 Socket for 14th/13th/12th Gen Intel® Core i Processors
Chipset	Intel® PCH R680E
Memory	2x DDR5 UDIMM 4800 MHz, up to 128 GB
Display	1x LCM
Ethernet	4x 2.5GbE RJ45 ports (Intel® i226V)4x 1GbE SFP ports (Intel® i210IS)2x 10GbE SFP+ (Intel® X710)
Bypass	1x Segment (MCU control)
Expansion	1x PCI-E Gen5 x8 (for SSL card)1x PCI-E Gen5 x8 (for IBN module)
IPMI	N/A
Storage	1x 2.5” HDD/SSD1x SATA DOM1x 2280 M.2 slot
TPM	TPM 2.0
I/O	1x LCM3x LED (Status/HDD/Power)1x RJ45 console2x USB 3.01x Reset button1x NMI button
Power Supply	600W 1+1 redundant power supply500W single power supply450W 1+1 redundant power supply
Dimensions	438(W) x 420(D) x 44(H) mm ± 0.3mm
Weight	N/A
Operating Temperature	0°C~ 50°C
Storage Temperature	-20° ~ 70°C
Operating Humidity	10% ~ 90%
Certification	CE/FCC
