IBRK100
ORDINATEURS MONOCARTES / EN STOCK

IBRK100

SBC Low-Power 2,5 po — MediaTek Genio 720 / MT8391 or MediaTek Genio 520/MT8371 Processor

SBC Low-Power 2,5 po — MediaTek Genio 720 / MT8391 or MediaTek Genio 520/MT8371 Processor. Soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

PROCESSEUR
MediaTek Genio 7202x A78 2.6GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cacheMediaTek Genio 5202x A78 2.2GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cache
MÉMOIRE
On-board LPDDR5(X) 6400MT/s, 4GB or 8GB
AFFICHAGE
1x HDMI (4K60) / 1x LVDS (FHD)1x DP over Type-C (2nd display only, 2560x1600)*HDMI and LVDS mutually exclusive
ENVIRONNEMENT
-20°C~+80°C (-4°F~176°F)
2.5 Disk Size SBCRISC based Single Board…
DEMANDER UNE SOUMISSION DEMANDER LA FICHE TECHNIQUE
P/N # IBRK100
Introduction au chien de garde

Spécifications

17 LIGNES
Format2.5-inch SBC
ProcesseurMediaTek Genio 7202x A78 2.6GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cacheMediaTek Genio 5202x A78 2.2GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cache
Mémoire systèmeOn-board LPDDR5(X) 6400MT/s, 4GB or 8GB
Mémoire flashOn-board 64GB or 128GB UFS flash for O.S.
Affichage1x HDMI (4K60) / 1x LVDS (FHD)1x DP over Type-C (2nd display only, 2560x1600)*HDMI and LVDS mutually exclusive
Codec vidéoDecode: 4K60fps, VP9, H.265, H.264Encode: 4K30fps, H.265, H.264
GraphiquesARM Mali-G57 MC2, OpenGL ES 3.2,Vulkan 1.1, OpenCL 2.2
E/S de bord1x COM port (RS-232/422/485)1x RJ45 GbE LAN port1x HDMI (4K60)1x On/Off button1x Reset button1x USB 3.2 Type-C2x USB 2.0 Type-A1x Micro SD Slot1x Audio Line-Out1x LED
E/S internes1x RS-232 (2-wire, Debug only)1x CAN-FD1x LED1x Download Button1x 4-Pin Slide Switch Auto Power/LCD Power/ Backlight Power control1x MIPI-CSI2 (4-Lane)1x RTC Battery Connector
E/S d’extension1x M.2 E-Key (2230) w/ PCIe Gen 2 x1, USB 2.04x GPIO
Chien de garde256 Levels, 0~128 Secs
Dimensions100mm x 72mm (3.94" x 2.83")
Entrée d’alimentation12V DC-in by DC-Connector
Température de fonctionnement-20°C~+80°C (-4°F~176°F)
Humidité relative90% (non-condensing @60°C)
Systèmes d’exploitation pris en chargeAndroid 16, Ubuntu 24.04, Other OS (by request)
CertificationCE/ FCC Class-B
