PCI-6S
6-slot passive backplane — 2x PICMG, 4x PCI, 1x ISA
6-slot passive backplane — 2x PICMG, 4x PCI, 1x ISA. Local warranty support and engineering customization available on request.
SLOTS
6 total — 2x PICMG, 4x PCI, 1x ISA
BUS
PICMG/PCI/ISA Passive
PICMG BackplanePassive Backplane
P/N # PCI-6S
Specifications
2 ROWS
| Bus Type | PICMG/PCI/ISA Passive |
|---|---|
| Slot Configuration | 6 total — 2x PICMG, 4x PCI, 1x ISA |
I/O — Rear panel
Front access
Where the PCI-6S is deployed
USE CASE
PICMG system builds
Backplane for PICMG 1.0/1.3 CPU cards already in the catalog (IB740, IB835, IB840, IB936, IB945, IB965, IB981).
USE CASE
Legacy system support
Drop-in replacement backplane for fielded industrial PC chassis.
USE CASE
Expansion & upgrades
Add ISA, PCI or PCIe expansion capacity to an existing PICMG-based system.
Have a specific use case?
Our applications engineers will match your environment, software stack and I/O requirements to the right platform — or modify this one.
TALK TO AN ENGINEERResources
- REQUEST →PCI-6S datasheetAvailable on request
- REQUEST →PCI-6S user manualAvailable on request
- REQUEST →Driver packageAvailable on request
- REQUEST →Declaration of Conformity (CE)Available on request
