BP0005
5-slot passive backplane — 2x PICMG, 3x PCI, 1x ISA
5-slot passive backplane — 2x PICMG, 3x PCI, 1x ISA. Local warranty support and engineering customization available on request.
SLOTS
5 total — 2x PICMG, 3x PCI, 1x ISA
BUS
PICMG/PCI/ISA Passive
PICMG BackplanePassive Backplane
P/N # BP0005
Specifications
2 ROWS
| Bus Type | PICMG/PCI/ISA Passive |
|---|---|
| Slot Configuration | 5 total — 2x PICMG, 3x PCI, 1x ISA |
I/O — Rear panel
Front access
Where the BP0005 is deployed
USE CASE
PICMG system builds
Backplane for PICMG 1.0/1.3 CPU cards already in the catalog (IB740, IB835, IB840, IB936, IB945, IB965, IB981).
USE CASE
Legacy system support
Drop-in replacement backplane for fielded industrial PC chassis.
USE CASE
Expansion & upgrades
Add ISA, PCI or PCIe expansion capacity to an existing PICMG-based system.
