MI8382

Name: MI8382
Brand: IBASE Technology
SKU: MI8382
Availability: InStock

Intel Alder Lake-N CPU, N100 (6w) or N97 (12w), 11xUSB, 6xCOM, 2xLAN, 2xM.2, 1xVGA, LVDS

Intel Alder Lake-N CPU, N100 (6w) or N97 (12w), 11xUSB, 6xCOM, 2xLAN, 2xM.2, 1xVGA, LVDS. Soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

PROCESSEUR

Intel Alder Lake-N, Core i3-N300 CPU

MÉMOIRE

DDR4-3200, 1*SO-DIMM, up to 16GB

STOCKAGE

1xSATA 3.0 · 1xM.2 (Key-B, 2242/2280, NVMe PCIe x1/ SATA SSD)

AFFICHAGE

1xHDMI: max resolution up to 4096*2160@60Hz · 1x optional VGA share the same place with HDMI and USB on I/O

DEMANDER UNE SOUMISSION DEMANDER LA FICHE TECHNIQUE

P/N # MI8382

Spécifications

19 LIGNES

Processeur	Intel Alder Lake-N, Core i3-N300 CPU
Mémoire	DDR4-3200, 1*SO-DIMM, up to 16GB
Stockage	1xSATA 3.0 · 1xM.2 (Key-B, 2242/2280, NVMe PCIe x1/ SATA SSD)
Interface d’extension	1xM.2 (Key-E, 2230, PCIe+USB 2.0, Wifi+BT)
BIOS	AMI UEFI BIOS
Série	6x RS232
USB	4x USB 3.0, 7x USB 2.0
Audio	Realtek 5.1 channel HDA Codec, with MIC/Line-out and Amplifier
Parallèle	1x LPT Header
Interface d’affichage	1xHDMI: max resolution up to 4096*2160@60Hz · 1x optional VGA share the same place with HDMI and USB on I/O
Canal d’affichage	Triple
Ethernet	1x Realtek 1Gbps PCIe Ethernet Controller, RJ45
GPIO	8x Programmable GPIO
Dimension	170x170mm
Entrée d’alimentation	DC 12V
Autres	1x Cash Drawer Control Wafer, 1x I2C Touch Wafer, 1x Case Open Header
En fonctionnement	0~60oC 10%~90%
Stockage	-25~+75oC at 5%~95%, non-condensing
Systèmes d’exploitation compatibles	Windows 10/11, Linux

Informations de commande

3 LIGNES

MI8382	- Intel N100 (Quad Core 6w) SoC on board Mini-iTx SBC VGA,LVDS,Dual Lan
MI8383	- Intel N300 (Octa Core 7w) SoC on board Mini-iTx SBC VGA,LVDS,Dual Lan
MI8389	- Intel N97 (Quad Core 12W) SoC on board Mini-iTx SBC VGA,LVDS,Dual Lan
