MI8380
INDUSTRIAL MOTHERBOARDS / IN STOCK

MI8380

Intel Core N-series CPU (N300/N97/N50), DDR4, 11xUSB, 6xCOM, 1xLAN, 2xM.2, HDMI/VGA/eDP-LVDS

Intel Core N-series CPU (N300/N97/N50), DDR4, 11xUSB, 6xCOM, 1xLAN, 2xM.2, HDMI/VGA/eDP-LVDS. Local warranty support and engineering customization available on request.

CPU
Intel Core N300 (Octa 7W) / N97 (Quad 6W) / N50 (Dual 6W)
MEMORY
1x DDR4 3200 SO-DIMM, Max. 16GB
STORAGE
1x SATA III · 2x M.2 sockets (E-key 2230 + B-key 2240/2280), PCIe Gen 3.0
DISPLAY
3x channel Display: HDMI, VGA & eDP or LVDS
P/N # MI8380

Specifications

24 ROWS
CPUIntel® Core™ N300 Processor (I3-N300 3.8GHz Octal)
PCHN/A
Memory1x DDR4 3200 SO-DIMM, Max. 16GB
BIOSAMI UEFI BIOS
Watchdog Timer256 levels
H/W MonitorYes
Storage Device InterfaceN/A, SATA III, NANO-SIM, M.2 2230
Mini Type Slots2x M.2 sockets (E-key+B-key) (PCIe Gen 3.0)
Graphics ControllerIntel® SoC integrated Gen12 graphics
Video Output3x channel Display [HDMI, VGA & eDP or LVDS]
Ethernet1x Realtek GBE LAN Chip (10/100/1000 Mbps, RJ45)
I/O Chipseton board
Serial Port1x RS232 (COM1 on edge), 5x RS232 on header
USB 2.04x USB 2.0 via (pin header), 2x TYPE-A on edge
USB 3.X4x USB 3.0 TYPE-A on edge
Serial ATA1x SATA III / with power on header
AudioIntel® Core™ i3 Processor N-series & Intel® Processor N-series built-in HD audio + ALC888S codec
TPMfTPM
OthersDigital I/O (4-in/4-out), 12V DC-in/ATx
Dimensions (L x W)102mm x 147mm (4“ x 5.8“)
Power ConsumptionTBD
Operating Temperature0°C~60°C (32°F~140°F)
Storage Temperature-20°C~75°C (-4°F~176°F)
Relative Humidity10% ~ 90% (non-condensing)
