MI1061D5

Name: MI1061D5
Brand: IBASE Technology
SKU: MI1061D5
Availability: InStock

Mini-ITX Motherboard with 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 / Pentium® / Celeron® DT Processors (H610 PCH), DDR5

Mini-ITX Motherboard with 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 / Pentium® / Celeron® DT Processors (H610 PCH) and DDR5 memory. Local warranty support and engineering customization available on request.

CPU

LGA1700

MEMORY

2x DDR5 UDIMM sockets, DDR5-5600, Max. 192GB

STORAGE

1x SATA III & NVMe

DISPLAY

1x HDMI (2.0b) 4K + 1x VGA 2K

Mini-ITX MotherboardMotherboard

REQUEST QUOTE DATASHEET (PDF)

P/N # MI1061D5

Diagram Introduction to Watchdog Timer

Specifications

20 ROWS

CPU Socket	LGA1700
CPU	Intel® Core™ 12th/13th/14th Gen i9/i7/i5/i3, Pentium®, Celeron® DT processors, up to 65W TDP
PCH	H610 (6W TDP)
Memory	2x DDR5 UDIMM sockets, DDR5-5600, Max. 192GB (64GB per socket)
BIOS	AMI UEFI
Storage Device Interface	1x SATA III, 2x M.2 (M-Key 2280 PCIe 4x, E-Key 2230 USB 2.0 + PCIe 1x)
Expansion Slots	1x PCI-E (x16) [Gen4]
Graphics Controller	Intel® integrated graphics
Video Output	1x HDMI (2.0b) 4K, 1x VGA 2K
Ethernet	Dual Gigabit LAN (Realtek RTL8111H)
Serial Port	10x COM ports: 2x RS232/422/485, 5x RS232, 1x TTL, 3x TTL
USB 2.0	8x USB 2.0
USB 3.X	4x USB 3.2 Gen2
Audio	HD Audio (Realtek codec), 1x Mic, 1x Line-Out
TPM	fTPM 2.0 (optional dTPM)
Others	PS/2, Digital I/O (4-in/4-out), Watchdog timer
Dimensions (L x W)	305mm x 244mm (12in x 9.6in)
Power Consumption	See datasheet
Operating Temperature	0°C~60°C ( 32°F~140°F)
Storage Temperature	-20°C~75°C (-4°F~167°F)
