IP10S
IP10S-R - 5.25-inch Disk-Size ETX Base Board
IP10S-R - 5.25-inch Disk-Size ETX Base Board. Local warranty support and engineering customization available on request.
STORAGE
-20°C~80°C (-7°F~4°F)
DISPLAY
LVDS interface (Hirose DF13) connector
ETHERNET
Two Intel® 82599 Fast Ethernet Controller · Pin headers for three RJ-45 connectors (one RJ-45 is for the built-in LAN on the ETX CPU module)
OPERATING TEMP.
0°C~60°C (32°F~140°F)
P/N # IP10S
Diagram Specifications
21 ROWS
| Ethernet Function | Two Intel® 82599 Fast Ethernet Controller · Pin headers for three RJ-45 connectors (one RJ-45 is for the built-in LAN on the ETX CPU module) |
|---|---|
| VGA Connector | Pin header for VGA CRT connector |
| LCD Panel Connector | LVDS interface (Hirose DF13) connector |
| IDE Interface | One enhanced IDE interface supports 2 IDE devices in UDMA/33/66/100, PIO mode 4 and bus master mode · Two 44-pin header connectors |
| FDD Interface | Pin header supports up to two floppy disk drives: 3.5"(720KB, 1.44MB or 2.88MB) and/or 5.25"(360KB or 1.2MB); with 3 Mode support |
| Serial Ports | Pin headers for two RS-232 ports (COM1 & COM2) |
| Parallel Port | One parallel port supports SPP/EPP/ECP |
| USB | Pin header for four (4) USB ports |
| IrDA | Pin header for infrared module |
| DiskOnChip Interface | DiskOnChip socket supports 2MB~144MB DiskOnChip flash disks |
| Mouse Connector | Pin header for PS/2 connector |
| Keyboard Connector | Pin header for PS/2 connector · 5-pin header for external keyboard connector |
| Fan Power Connector | System fan power connector · CPU fan power connector |
| Other Connectors | TV out connector · IrDA connector · Backlight control · System Function connector · Main Power connector · Audio connector · CD-In connector · ATX Power Control connector |
| On board Jumpers | DiskOnChip Address Select · COM2 RS232/422/485 Select · Onboard LAN1 Select · Onboard LAN2 Select · LCD Power Setting |
| Expansion Slots | One 32-bit PCI slot · One PC/104 connector |
| Form Factor | 5.25-inch Disk-Size form factor |
| Dimensions | 203mm x 146mm |
| Operating Temperature | 0°C~60°C (32°F~140°F) |
| Storage Temperature | -20°C~80°C (-7°F~4°F) |
| Relative Humidity | 10%~90% (non-condensing) |
I/O — Rear panel
Front access
Where the IP10S is deployed
USE CASE
Compact OEM design-in
Space-constrained products needing a certified compute module rather than a full board.
USE CASE
Long-lifecycle carrier designs
Custom carrier boards built around a standardized, sourceable CPU module.
USE CASE
Medical & instrumentation
Low-power modules for diagnostic and portable instrument designs.
USE CASE
Robotics & automation
Compact compute modules for motion controllers and mobile robotics platforms.
Have a specific use case?
Our applications engineers will match your environment, software stack and I/O requirements to the right platform — or modify this one.
TALK TO AN ENGINEERResources
- DOWNLOAD ↓IP10S datasheetPDF document
